The most common question we get is " What size nozzle should I use ?"
The goal is to achieve the Evaporative Cooling Effect without getting people or furniture wet. One size certainly does not fit all. There are many factors which will determine the nozzle size that should be used for a given location. The primary factors are
1. Temperature
2. Humidity
3. Nozzle mounting height
4. Air flow through the area
Consider the following extreme examples:
Example 1: A free standing pergola with an open top in Arizona.
This structure will experience very high evaporation/cooling due to the high temperatures and very low humidity, In addition, because of the 4 open sides and top, maximum flow through air will facilitate the evaporation and therefor cooling.
Example 2: A patio in Florida which has just one open side. The other three sides are walls of the house. The ceiling is covered.
This structure will experience low evaporation/cooling due the the high humidity and low flow through air. Misting Fans would be a better choice for this example.
Most all structures will fall between these two extremes
It is important to note that each patio has additional variables that can affect the evaporation including: wind, sun or shade, in addition to the above factors.
For High Pressure misting, the cooling is provided by The Evaporative Cooling Effect and not by getting folks wet.
Here are some general guidelines for choosing the proper nozzle size
.004" ( .10mm)
These are the smallest nozzles available. They create a super fine mist that will evaporate quickly in most conditions.
Use these nozzles for the following applications:
- Climates with very high humidity ( over 60% ) and nozzle height of around 8' ( i.e. Florida ).
Note that these nozzles are so fine that additional filtration is strongly suggested to avoid clogging.
.006" ( .15mm )
Use these nozzles for the following applications:
- Relatively dry climates with low nozzle height around 7- 8' and temperatures in the 90's to low 100's ( i.e. California )
- Moderately humid climates with temperatures in the 90's to low 100's and patio height 8'-9' ( i.e. parts of Texas, California )
.008" ( .20mm)
Use these nozzles for the following applications:
- Dry climates with temperatures in the 90's to high 100's and nozzle height around 8' ( i.e. Arizona )
- Relatively dry climates with temperatures in the 90's to low to mid 100's and patio height around 8'-9' (i.e California )
.012" (.30mm )
Use these nozzles for the following applications:
- Extremely dry climates with temperatures in the high 100's and patio height around 9'-10' ( i.e. Arizona )
If you have chosen one of our app controlled pumps, you have the additional benefit of using the interval spraying feature to regulate the mist. Please read the article " The Magic Of Interval Spraying "
